ROTOR DISC » RN2301V

RN2301V

Specification

Type
Vented
Outter Ø
310
Num. of holes
12
Hole Ø:
12.2
Disc Thickness (Max)
42
Disc Thickness (Min)
39
Height
55.6
Centering Diameter
110
Pitch Circle Ø
136
Drum Ø:
160
Front/Rear
Front
Structure Material
G3000

Cross Reference

ISUZU
8-97168-632-1
ISUZU
8-97371-877-0
ISUZU
8-97387-228-0
ISUZU
8-98105-058-0
ISUZU
8-98171-034-0
ISUZU
8-98248-895-0
ISUZU
8-98248-895-1
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

ISUZU   »   ELF

05.99~05.11 5200 4HK1-TCN NPR75U RN2301V PN4491BL1032 FN4401 FN4443

ISUZU   »   Truck

01.09~01.14 5200 4HK1-TCN NPR75U RN2301V PN4491 BL1032FN4401 FN4443
