ROTOR DISC » RN2033V

RN2033V

Specification

Type
Vented
Outter Ø
292.8
Num. of holes
6
Disc Thickness (Max)
40
Height
54
Centering Diameter
114
Drum Ø:
164
Pitch Circle Ø
140
Disc Thickness (Min)
37
Front/Rear
Front
Structure Material
G3000

Cross Reference

MITSUBISHI
MC 894846
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   Canter

01.13~ 3000 4D33 FE84C EU LHD RN2033V PN3513 RN1927V PN3513 FN4466
02.07~03.13 3000 4M42 FE84B EU LHD RN2033V PN3513 RN1927V PN3513 FN4466
04.95~04.04 3900 4D34-T FE649 RN1451VRN2033V FN6653PN3407BL1060 RN1927V FN6653PN3407 FN4443
