ROTOR DISC » RN1194V
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
5
Height
48.5
Centering Diameter
72
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
300
Drum Ø:
140
Disc Thickness (Min)
23
Structure Material
G3000
Cross Reference
MAZDA
BP6Y3325XD
MAZDA
BP6Y3325XE
MAZDA
BP6Y3325XF
MAZDA
C26Y3325X
MAZDA
C26Y3325XA
MAZDA
C26Y3325XB
MAZDA
C26Y3325XD
OEM
C26Y3325XB
OEM
C26Y3325XC
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.06~05.09 | 2300 | L3-VDT | BK3P | RN2386VRN1194V | PN0365PN0352 | RN1373 | PN2702 | |
| 10.03~06.09 | 2300 | L3-VE | BK3P | RN1194V | PN0365 | RN1373 | PN2702 |
| 07.08~05.13 | 2000 | LF-VD | CCEAW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 07.08~05.13 | 2000 | LF-VD | CCEFW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 06.09~05.13 | 2000 | LF-VDS | CCEFW | RN1194V | PN0365 | RN25001 | PN2702 | |
| 05.13~03.18 | 2000 | PE-VPS | CC1071 RHD | RN1194V | PN0365 | RN25001 | PN2702 | |
| 05.13~03.18 | 2000 | PE-VPS | CCFFW JPN | RN1194V | PN0365 | RN25001 | PN2702 | |
| 07.08~05.13 | 2300 | L3-VE | CC3FW | RN1194V | PN0365 | RN25001 | PN2702 |
| 12.10~05.15 | 1500 | ZY-VE | DE 5DR HB | RN2495VRN1903VRN1194V | PN0544PN5562 | DN1408 | FN0630 | |
| 12.10~05.15 | 1500 | ZY-VE | DE SDN | RN1903VRN1194VRN2495V | PN5562PN0544 | DN1408 | FN0630 |
| 01.03~03.09 | 2000 | LF# | BK HB | RN1194V | PN0365 | RN1373 | PN2702 | |
| 06.03~07.06 | 2000 | LF# | BK HB | RN1194V | PN0365 | RN1373 | PN2702FN3427 | |
| 11.08~11.11 | 2000 | LF# | JMZBL HB | RN1194V | PN0365 | RN1373 | PN2702 | |
| 03.06~03.09 | 2000 | LF-VE | AEBA11 SDN RU | RN1194V | PN0365 | RN1373 | PN2702 | |
| 01.03~03.09 | 2000 | LF-VE | JM6BK SDN | RN1194V | PN0365 | RN1373 | PN2702 | |
| 03.06~03.09 | 2000 | RF-T | BK | RN1194V | RN1373 | PN2702 | ||
| 01.03~08.11 | 2300 | L3-VE | BK | RN1194V | RN1373 | PN2702 |
| 06.10~08.17 | 1600 | Y6 | CW | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 1800 | L8 | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 02.05~10.10 | 1800 | L823 | CR | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 2000 | LF-VE | CW | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 2000 | LF5H | CW | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR19 EU LHD | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 10.10~08.17 | 2000 | PE-VPS | CW | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 02.05~06.10 | 2000 | RF7J | CR | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 03.08~10.10 | 2300 | L3-V# | AUCV02 US | RN1193VRN1194V | PN0365 | RN25001 | PN2702 | |
| 09.04~03.08 | 2300 | L3-VE | CR | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 06.10~08.17 | 2500 | L5-VE | CW | RN1194V | PN0365 | RN25001 | PN2702 |
