DRUM BRAKE » DN1408

DN1408

Specification

Outter Ø
240
Num. of holes
4
Hole Ø
14
Centering Diameter
55
Height
57.4
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

MAZDA
DF71-26-251
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MAZDA   »   Demio

05.07~09.14 1300 ZJ-VE DE3AS RN1903V PN0544 DN1408 FN0630

MAZDA   »   Mazda 2

06.11~11.14 1300 P3-VPS DE RN1512V PN5562 DN1408 FN0630
06.07~01.14 1400 Y4 DE RN1512V PN5562 DN1408 FN0630
06.07~05.15 1500 ZY-DE DE RN1512V PN5562 DN1408 FN0630
04.07~12.10 1500 ZY-VE DE RN1512V PN5562 DN1408 FN0630
12.10~05.15 1500 ZY-VE DE 5DR HB RN1903VRN1194VRN2495V PN0544PN5562 DN1408 FN0630
12.10~05.15 1500 ZY-VE DE SDN RN1194VRN2495VRN1903V PN5562PN0544 DN1408 FN0630
06.07~01.14 1600 Y6 DE RN1512V PN5562 DN1408 FN0630
08.10~01.14 1600 Z6 DE RN1512V PN5562 DN1408 FN0630
