ROTOR DISC » RN1373
Specification
Type
solid
Disc Thickness (Max)
11
Num. of holes
5
Height
40.8
Centering Diameter
72
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
280
Disc Thickness (Min)
9
Drum Ø:
153
Structure Material
G3000
Cross Reference
MAZDA
BP6Y26251B
MAZDA
BP6Y26251C
MAZDA
BP6Y26251D
MAZDA
BP6Y26251E
MAZDA
C25Y-26-251C
MAZDA
C25Y26251A
MAZDA
C25Y26251B
OEM
BP6Y23251B
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.06~05.09 | 2300 | L3-VDT | BK3P | RN1194VRN2386V | PN0365PN0352 | RN1373 | PN2702 | |
| 06.09~09.11 | 2300 | L3-VDT | BL3FW | RN2386V | PN0352 | RN1373 | PN2702 | |
| 09.11~11.13 | 2300 | L3-VDT | BL3FW | RN2386V | PN0352PN0365 | RN1373 | PN2702 | |
| 10.03~06.09 | 2300 | L3-VE | BK3P | RN1194V | PN0365 | RN1373 | PN2702 |
| 01.03~03.09 | 2000 | LF# | BK HB | RN1194V | PN0365 | RN1373 | PN2702 | |
| 06.03~07.06 | 2000 | LF# | BK HB | RN1194V | PN0365 | RN1373 | PN2702FN3427 | |
| 11.08~11.11 | 2000 | LF# | JMZBL HB | RN1194V | PN0365 | RN1373 | PN2702 | |
| 03.06~03.09 | 2000 | LF-VE | AEBA11 SDN RU | RN1194V | PN0365 | RN1373 | PN2702 | |
| 01.03~03.09 | 2000 | LF-VE | JM6BK SDN | RN1194V | PN0365 | RN1373 | PN2702 | |
| 03.06~03.09 | 2000 | RF-T | BK | RN1194V | RN1373 | PN2702 | ||
| 01.09~11.13 | 2200 | SH-VPTS | BL | PN0365 | RN1373 | PN2702 | ||
| 07.06~03.09 | 2300 | L3-VDT | 5DR HB US | RN2386V | PN0352 | RN1373 | PN2702 | |
| 03.06~03.09 | 2300 | L3-VDT | ABBA11 HB | RN2386V | PN0352 | RN1373 | PN2702 | |
| 01.03~03.09 | 2300 | L3-VDT | BK | RN2386V | PN0352 | RN1373 | PN2702 | |
| 01.09~11.13 | 2300 | L3-VDT | BL HB | RN2386V | PN0352 | RN1373 | PN2702 | |
| 01.03~08.11 | 2300 | L3-VE | BK | RN1194V | RN1373 | PN2702 | ||
| 01.09~11.13 | 2300 | L3-VE | BL | PN0352 | RN1373RN1369 | PN2702 | ||
| 02.09~11.13 | 2500 | L5-VE | BL | PN0365 | RN1373 |
| 06.10~08.17 | 1600 | Y6 | CW | RN1194VRN1193V | PN0365 | RN1373RN25001 | PN2702 | |
| 06.10~08.17 | 1800 | L8 | CW | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 | |
| 02.05~10.10 | 1800 | L823 | CR | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 06.10~08.17 | 2000 | LF-VE | CW | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 06.10~08.17 | 2000 | LF5H | CW | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR | RN1194VRN1193V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | LFF7 | CR19 EU LHD | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 10.10~08.17 | 2000 | PE-VPS | CW | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 02.05~06.10 | 2000 | RF7J | CR | RN1193VRN1194V | PN0365 | RN25001RN1373 | PN2702 | |
| 09.04~03.08 | 2300 | L3-VE | CR | RN1193VRN1194V | PN0365 | RN1373RN25001 | PN2702 |
