ROTOR DISC » RN1166V

RN1166V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
4
Height
41.2
Centering Diameter
60
Front/Rear
Front
Outter Ø
240
Drum Ø:
126
Pitch Circle Ø
100
Hole Ø:
14.3
Disc Thickness (Min)
17
Structure Material
G3000

Cross Reference

BENDIX
561248B
BENDIX
562290B
OPEL
0569021
OPEL
9195985
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

OPEL   »   Corsa C

09.00~11.06 1000 Z10XE RN1166V PN0361 DN1852DN1578 FN0533FN11622
11.00~11.03 1200 Z12XE X01 RN1166V PN0361 DN1852 FN11622
07.04~06.07 1200 Z12XEP RN1166V PN0361 DN1578DN1852 FN11622FN0533
09.00~11.06 1700 Y17DT RN1166V PN0361 DN1578DN1852 FN11622FN0533
