ROTOR DISC » RN1154V

Specification

Type
Vented
Disc Thickness (Max)
30
Num. of holes
5
Height
62.1
Centering Diameter
75
Front/Rear
Front
Outter Ø
332
Disc Thickness (Min)
28.5
Pitch Circle Ø
120
Drum Ø:
158
Structure Material
G3000

Cross Reference

BENDIX
562134B
BMW
34 11 6 859 679
BMW
34116750713
BMW
34116756045
BMW
34116765457
BMW
34116766036
BMW
34116794300
BMW
34116794304
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.06~08.10 3000 M57D30(306D5) E83 RN1154V PN0401 RN2382V PN0225 FN0589
04.01~09.03 3000 M57D30(306D1) E53 RN1154V PN0401 RN1155 PN0225 FN0589
10.03~09.06 3000 M57D30(306D2) FB71 RN1154V PN0401 RN1155 PN0225 FN0589
04.00~09.06 3000 M54B30(306S3) E53 RN1154V PN0401 RN1155 PN0225 FN0589
01.01~09.03 4400 M62B44(448S) E53 RN1154V PN0401 RN1155 PN0225 FN0589
09.03~09.06 4400 N62B44 FB5 RN1154V PN0401 RN1922V PN0225 FN0589
09.03~09.06 4400 N62B44 FB52 RN1154V PN0401 RN1922V PN0225 FN0589

Exemption from liability: the catalog data is advisory and can be used for reference only
