ROTOR DISC » RN1155

Specification

Type
Solid
Disc Thickness (Max)
12
Num. of holes
5
Height
80
Centering Diameter
75
Front/Rear
Rear
Outter Ø
324
Disc Thickness (Min)
10.5
Pitch Circle Ø
120
Drum Ø:
185
Structure Material
G3000

Cross Reference

BENDIX
562135B
BENDIX EUR
562135B
BMW
34 21 6 859 678
BMW
34211164911
BMW
34216765458
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.01~09.03 3000 M57D30(306D1) E53 RN1154V PN0401 RN1155 PN0225 FN0589
10.03~09.06 3000 M57D30(306D2) FB71 RN1154V PN0401 RN1155 PN0225 FN0589
04.00~09.06 3000 M54B30(306S3) E53 RN1154V PN0401 RN1155 PN0225 FN0589
01.01~09.03 4400 M62B44(448S) E53 RN1154V PN0401 RN1155 PN0225 FN0589

Exemption from liability: the catalog data is advisory and can be used for reference only
