ROTOR DISC » RN1138V
Specification
Type
Vented
Disc Thickness (Max)
21
Num. of holes
4
Height
39
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
240
Hole Ø:
12.7
Drum Ø:
122
Disc Thickness (Min)
19
Structure Material
G3000
Cross Reference
BENDIX
562142B
HONDA
45251-S2G-000
HONDA
45251-S50-G00
HONDA
45251-S50-J00
HONDA
45251-SAA-G00
HONDA
45251-SAA-G10
HONDA
45251-SAA-G11
HONDA
45251-SAA-G12
HONDA
45251-SAD-M00
HONDA
45251-SEL-T00
HONDA
45251-SEL-T10
HONDA
45251-SEM-K00
HONDA
45251-SEM-T00
HONDA
45251-TJ0-M00
OEM
45251S50SG00
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.03~01.08 | 1200 | L12A2/3 | GE1 | RN1138V | PN8265 | FN5546 | ||
| 01.04~12.08 | 1200 | REGD# | CD6 | RN1138V | PN8265 | FN5546 | ||
| 01.02~01.06 | 1300 | L13A# | GD6 LHD | RN1138V | PN8265 | DN1382 | FN5546 | |
| 01.06~01.09 | 1300 | L13A# | GD6 LHD | RN1138V | PN8265 | DN1382 | FN5546 | |
| 01.03~12.08 | 1300 | L13A3 | GE4 | RN1138V | PN8265 | FN5546 | ||
| 11.02~09.05 | 1500 | L15A1 | HGD8 RHD | RN1138V | PN8265 | RN1052DN1382 | FN5546PN8206 | |
| 09.05~01.08 | 1500 | L15A1 | HGD8 RHD | RN1138V | PN8265 | RN1052DN1382 | PN8206FN5546 | |
| 01.03~12.08 | 1500 | L15A3 | GD8 | RN1138V | PN8265 | FN5546 | ||
| 01.04~12.08 | 1500 | REFD# | CD8 | RN1138V | PN8265 | RN1052 | PN8206 |
| 06.01~09.07 | 1300 | L13A(i-DSI) | GD2 | RN1138V | PN8265 | FN5520 | ||
| 10.07~03.14 | 1400 | L13Z | GE6 LHD | RN1138V | PN8826 | DN1377 | FN5538 | |
| 06.01~09.07 | 1500 | L15A | GD3 JPN | RN1376VRN1138V | PN8265 | DN1382RN1052 | FN5534PN8206 | |
| 06.01~09.07 | 1500 | L15A | GD4 | RN1138V | PN8265 | FN5520 |
| 12.02~09.05 | 1300 | L13A | GD7 | RN1138V | PN8265 | FN5520 | ||
| 12.02~01.09 | 1500 | L15A | GD8 | RN1138V | PN8265 | DN1382 | FN5534 | |
| 11.02~01.09 | 1500 | L15A | GD9 | RN1138V | PN8265 | FN5520 |
| 01.02~12.04 | 1200 | L12A1 | GD5 | RN1138VRN1376V | PN8265 | RN1047DN1382RN1052 | PN8206FN5534 | |
| 11.08~09.15 | 1200 | L12B | GE1 | RN1138V | PN8265PN8868 | RN1052 | PN8206 | |
| 01.02~05.09 | 1300 | L13A1 | JHMGD1 RHD | RN1138VRN1376V | PN8265 | DN1382RN1052 | PN8206FN5534 | |
| 07.08~ | 1300 | L13Z1 | GG3 | RN1138V | PN8265 | RN1642 | PN8206 | |
| 01.02~12.08 | 1500 | L15A | GD1 | RN1138V | PN8265 | FN5534 | ||
| 01.02~12.08 | 1500 | L15A1 | GD3 LHD | RN1138V | PN8265 | DN1382 | FN5534 | |
| 01.02~12.08 | 1500 | L15A1 | GD3 RHD | RN1138V | PN8265 | DN1382 | FN5534 |
