BRAKE SHOE » FN5546

Specification

Radius
90
Width
30
Thickness
6
Pcs In Set
4

Cross Reference

BENDIX AUS
BS5038
HONDA
43153-SEL-003
HONDA
43153-SEL-T01
HONDA
43153-SEN-H01
KASHIYAMA
K5546
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.03~01.08 1200 L12A2/3 GE1 RN1138V PN8265 FN5546
01.04~12.08 1200 REGD# CD6 RN1138V PN8265 FN5546
01.02~01.06 1300 L13A# GD6 LHD RN1138V PN8265 DN1382 FN5546
01.06~01.09 1300 L13A# GD6 LHD RN1138V PN8265 DN1382 FN5546
01.03~12.08 1300 L13A3 GE4 RN1138V PN8265 FN5546
04.06~12.08 1500 L15A1 GUAN - CITY PN8265 PN8206FN5546
11.02~09.05 1500 L15A1 HGD8 RHD RN1138V PN8265 DN1382RN1052 PN8206FN5546
09.05~01.08 1500 L15A1 HGD8 RHD RN1138V PN8265 DN1382RN1052 FN5546PN8206
01.03~12.08 1500 L15A3 GD8 RN1138V PN8265 FN5546
01.02~12.08 1500 L15A GD8 RN1138V PN8824PN8265 DN1382RN1052 FN5546PN8206

Exemption from liability: the catalog data is advisory and can be used for reference only
