ROTOR DISC » RN1376V

RN1376V

Specification

Type
Vented
Disc Thickness (Max)
21
Num. of holes
4
Height
39.2
Centering Diameter
64.2
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
257.7
Drum Ø:
141
Disc Thickness (Min)
19
Structure Material
G3000

Cross Reference

HONDA
45251-SAA-G50
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HONDA   »   Fit

06.01~09.07 1300 L13A(i-DSI) GD1 JPN RN1376VRN1350V PN8265PN8263 RN1052DN1382 FN5534PN8206
06.01~09.07 1500 L15A GD3 JPN RN1138VRN1376V PN8265 DN1382RN1052 PN8206FN5534

HONDA   »   Jazz

01.02~06.09 1200 L12A1 GD5 RN1376VRN1138V PN8265 DN1382RN1052RN1047 PN8206FN5534
09.05~05.09 1300 L13A1 JHMGD1 LHD RN1376V PN8265 RN1052 PN8206
01.02~05.09 1300 L13A1 JHMGD1 RHD RN1138VRN1376V PN8265 RN1052DN1382 FN5534PN8206
