ROTOR DISC » RN1023
Specification
Type
Solid
Disc Thickness (Max)
12.6
Num. of holes
5
Height
61.2
Centering Diameter
101.7
Front/Rear
Rear
Outter Ø
289.6
Disc Thickness (Min)
11.7
Cross Reference
BENDIX
561353B
LAND ROVER
571912
LAND ROVER
FRC9831
LAND ROVER
FTC1381
LAND ROVER
FTC461
LAND ROVER
LR017953
OEM
FRC8748
OEM
R571912
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.95~ | 2500 | 10P | DH# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 01.95~ | 2500 | 10P | LD | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 09.90~12.94 | 2500 | 11L | DH# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | FN0605 |
| 01.95~01.99 | 2500 | 16L | DH# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 01.95~01.99 | 2500 | 16L | LD | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 09.90~12.94 | 2500 | 17H | DH# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | FN0605 |
| 01.95~ | 2500 | 10P | DK# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 01.95~ | 2500 | 10P | LD | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 09.90~12.94 | 2500 | 11L | DK# | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | FN0605 |
| 01.95~ | 2500 | 16L | DK# | RN1025RN1284V | PN0243 | RN1023 | PN0276 | |
| 01.95~ | 2500 | 16L | LD | RN1284VRN1025 | PN0243 | RN1023 | PN0276 | |
| 09.90~08.93 | 3500 | 21G | DKA | RN1025RN1284V | PN0243 | RN1023 | PN0276 | FN0605 |
| 07.07~02.16 | 2400 | Duratorq-TDCi (140PS)-Puma | LD | RN1025 | PN0243 | RN1023 | PN0237 | |
| 09.87~03.06 | 2500 | TD5 | L316 | RN1025RN1284V | PN0243 | DN1631RN1023 | PN0237FN0501 | |
| 04.98~12.06 | 2500 | TD5 | LD | RN1025RN1284V | PN0243 | RN1023 | PN0237 | FN0501 |
| 10.89~06.94 | 2500 | 12L | LJG# | RN1025RN1284V | PN0238WPN0236 | RN1023 | PN0237 | FN0605 |
| 07.94~12.98 | 2500 | 17L | LJG# | RN1284VRN1025 | PN0238W | RN1023 | PN0237 | |
| 07.94~12.98 | 2500 | 19L | LJG# | RN1025RN1284V | PN0238W | RN1023 | PN0237 | |
| 07.94~12.98 | 2500 | 21L | LJG# | RN1025RN1284V | PN0238W | RN1023 | PN0237 | |
| 07.94~12.98 | 2500 | 22L | LJG# | RN1284VRN1025 | PN0238W | RN1023 | PN0237 | |
| 10.89~06.94 | 3500 | 22D | LJG# | RN1284VRN1025 | PN0238W | RN1023 | PN0237 | FN0605 |
| 10.89~06.94 | 3500 | 36L | LJG# | RN1025RN1284V | PN0238W | RN1023 | PN0237 | FN0605 |
| 10.89~06.94 | 3500 | 38L | LJG# | RN1025RN1284V | PN0238W | RN1023 | PN0237 | FN0605 |
| 07.94~12.98 | 4000 | 35L | LJG# | RN1284VRN1025 | PN0238W | RN1023 | PN0237 | |
| 07.94~12.98 | 4000 | 37L | LJG# | RN1284VRN1025 | PN0238W | RN1023 | PN0237 |
| 09.91~04.94 | 2500 | 14L | HA# | RN1025 | PN0238WPN0295 | RN1023 | PN0237PN0009 | |
| 09.91~04.94 | 2500 | 14L | HBM | RN1025 | PN0238WPN0295 | RN1023 | PN0237PN0009 | |
| 09.91~04.94 | 2500 | VM95A | HA# | RN1025 | PN0238W | RN1023 | PN0237 | |
| 09.91~04.94 | 2500 | VM95A | HAB | RN1025 | PN0238W | RN1023 | PN0237 | |
| 09.91~04.94 | 2500 | VM95A | HBM | RN1025 | PN0238W | RN1023 | PN0237 | |
| 10.89~04.94 | 4000 | 35D | LH | RN1025 | PN0238WPN0295 | RN1023 | PN0237PN0009 | |
| 10.89~04.94 | 4000 | 36D | LH | RN1025 | PN0295PN0238W | RN1023 | PN0237PN0009 | |
| 10.89~04.94 | 4000 | 37D | LH | RN1025 | PN0238W | RN1023 | PN0237 | |
| 10.89~04.94 | 4000 | 38D | LH | RN1025 | PN0238W | RN1023 | PN0237 | |
| 09.91~04.94 | 4200 | 40D | LH | RN1284V | PN0238W | RN1023 | PN0237 |
