NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2016V

ROTOR DISC » RN2016V

Specification

Type

Vented

Outter Ø

229

Num. of holes

4

Disc Thickness (Max)

18

Height

40

Centering Diameter

55

Pitch Circle Ø

100

Drum Ø:

129

Front/Rear

Front

Structure Material

G3000

Hole Ø:

14.5

Disc Thickness (Min)

17

Cross Reference

DAIHATSU

43512-97504

DAIHATSU

43512-97504-000

DAIHATSU

43512-97505-000

DAIHATSU

43512-97506-000

TOYOTA

43512-97505

TOYOTA

43512-97506

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

DAIHATSU » Atrai

05.99~05.05	660	EF	S220G	RN2016V	PN6341		FN0038 FN0029
12.98~05.05	660	EF-#	S230G	RN2016V	PN6341		FN0038 FN0029
07.00~01.05	1300	K3-VE	S221G	RN2016V	PN6341

TOYOTA » Sparky

01.00~03.03

1300

K3-VE

S221E

RN2016V

PN6341

FN0041
