ROTOR DISC » RN2547

Specification

Type
Vented
Outter Ø
308
Num. of holes
6
Hole Ø:
11.2
Disc Thickness (Max)
16.5
Disc Thickness (Min)
14.5
Height
78.3
Centering Diameter
110
Pitch Circle Ø
134
Drum Ø:
190
Front/Rear
Rear
Structure Material
G3000

Cross Reference

MAXUS
C00076503
MAXUS
C00178147
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.20~ 2000 SC20M150Q5 RN2546V PN6063 RN2547 PN6064PN6065
07.20~ 2000 SC20M163Q6A RN2546V PN6063 RN2547 PN6065PN6064

Exemption from liability: the catalog data is advisory and can be used for reference only
