ROTOR DISC » RN2546V

Specification

Type
Vented
Outter Ø
309
Num. of holes
8
Hole Ø:
14.8
Disc Thickness (Max)
31
Disc Thickness (Min)
29
Height
65.1
Centering Diameter
72.2
Pitch Circle Ø
102
Drum Ø:
136.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

MAXUS
C00074527
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.20~ 2000 SC20M150Q5 RN2546V PN6063 RN2547 PN6064PN6065
07.20~ 2000 SC20M163Q6A RN2546V PN6063 RN2547 PN6064PN6065

Exemption from liability: the catalog data is advisory and can be used for reference only
