ROTOR DISC » RN1787V
Specification
Type
Vented
Outter Ø
231
Num. of holes
4
Disc Thickness (Max)
17
Height
49.2
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
125
Structure Material
G3000
Disc Thickness (Min)
15
Front/Rear
Front
Cross Reference
MARUTI
55311M66R00
MARUTI
55311M69P00
MARUTI
55311M75F00
MARUTI
55311M75J20
MARUTI
55311M75J30
MARUTI
55311M75J40
MARUTI
55311M75J50
NISSAN
40206-4A00A
NISSAN
40206-4A00C
NISSAN
40206-4A0A0
SUZUKI
55311-75F11
SUZUKI
55311-M75J30
SUZUKI
5531175F00
SUZUKI
5531175F10
SUZUKI
55311M66R00
SUZUKI
55311M66R00-000
SUZUKI
55311M75F00
SUZUKI
55311M75J30-000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.09~09.12 | 1200 | K12M | RN1787V | PN9529 | ||||
| 09.12~ | 1200 | K12M | RN1787V | PN9529 | ||||
| 04.09~09.12 | 1300 | D13A | RN1787V | PN9529 | ||||
| 09.12~ | 1300 | D13A | RN1787V | PN9529 |
| 04.10~12.11 | 1200 | K12M | RN1787V | PN9529 | ||||
| 08.11~02.18 | 1200 | K12M | ZF62S | RN1787V | PN9529 | FN9807 | ||
| 04.07~08.11 | 1300 | D13A | RN1787V | PN9529 | ||||
| 08.11~ | 1300 | D13A | RN1787V | PN9529 | FN9807 | |||
| 04.05~03.10 | 1300 | G13B | RN1787V | PN9529 |
| 04.10~03.12 | 1200 | K12M | RN1787V | PN9529 | ||||
| 02.12~ | 1200 | K12M | RN1787V | PN9529 | FN9807 | |||
| 03.08~03.12 | 1300 | D13A | RN1787V | PN9529 | ||||
| 02.12~ | 1300 | D13A | RN1787V | PN9529 | FN9807 | |||
| 03.08~01.10 | 1300 | G13B | RN1787V | PN9529 |
| 01.06~12.10 | 1100 | F10D | RN1787V | PN9426 | ||||
| 01.00~12.03 | 1100 | FC | RN1787V | PN9426 | ||||
| 01.03~12.06 | 1100 | FC | RN1787V | PN9426 |
| 04.02~02.06 | 660 | K6A# | MG21S | RN1787VRN1986 | PN9426PN9523 | FN9959FN9967 | ||
| 02.06~02.11 | 660 | K6A# | MG22S | RN1787VRN1985 | PN9523 | FN9967 |
| 10.98~08.04 | 1000 | K10A | HA62S | RN1787V | PN9426 | FN9967FN9959 | ||
| 02.23~ | 1000 | K10CN | FM61S LHD | RN1787V | ||||
| 06.02~04.04 | 1100 | F10D | FF21 | RN1787V | ||||
| 06.05~12.09 | 1100 | F10D | RF410 | RN1787V | PN9443 | FN9959 |
| 09.14~ | 1400 | K14B | AVB414 | RN2245VRN1787V | PN9529 | FN9807FN9991 | ||
| 08.18~ | 1500 | K15B | AVB415-2 LHD | RN1787V | FN9807 |
| 08.11~01.14 | 1200 | K12M | ZC62S HB LHD | RN1787V | PN9529 | FN9807 | ||
| 08.11~02.18 | 1200 | K12MN | AZI412 SDN | RN1787V | PN9529 | FN9807 | ||
| 02.13~02.18 | 1200 | K12MN | AZI412 SDN TYPE 2 RHD | RN1787V | PN9529 | FN9807 | ||
| 10.13~05.18 | 1200 | K12MN | ZC62S HB LHD | RN1787V | PN9529 | FN9807 | ||
| 08.11~02.18 | 1200 | K12MN | ZC62S HB RHD | RN1787V | PN9529 | FN9807 | ||
| 08.11~02.18 | 1200 | K12MN | ZC62S HB RHD | RN1787V | PN9529 | FN9807 | ||
| 08.11~01.15 | 1200 | K12MN | ZF62S SDN RHD | RN1787V | PN9529 | FN9807 | ||
| 01.15~02.18 | 1200 | K12MN | ZF62S SDN RHD | RN1787V | PN9529 | FN9807 |
