ROTOR DISC » RN1713
Specification
Type
Solid
Outter Ø
305
Num. of holes
5
Disc Thickness (Max)
11
Disc Thickness (Min)
9.5
Height
71.4
Pitch Circle Ø
114.3
Drum Ø:
190
Centering Diameter
69
Structure Material
G3000
Cross Reference
HYUNDAI
58411-C5000
HYUNDAI / KIA
58411-C6000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.14~04.18 | 2000 | G4KH | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~11.20 | 2400 | G4KE | UM | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~11.20 | 2400 | G4KJ | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~10.20 | 3300 | G6DF | UM | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 08.14~04.18 | 3300 | G6DH | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 08.14~01.18 | 2000 | D4HA | PC | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2200 | D4HB | PC515 LHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~07.17 | 2200 | D4HB | PC515 LHD KDOM | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2200 | D4HB | PC515 RHD | RN1652VRN1349V | PN0662 | RN2008VRN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2400 | G4KE | PC515 LHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2400 | G4KE | PC515 RHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 3300 | G6DF | UM | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
