ROTOR DISC » RN1652V
Specification
Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
28
Height
49
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Disc Thickness (Min)
26.4
Drum Ø:
143
Structure Material
G3000
Cross Reference
HYUNDAI
51712-2W000
HYUNDAI / KIA
51712-4Z000
HYUNDAI / KIA
51712-C6000
HYUNDAI / KIA
51712-S1000
HYUNDAI / KIA
51712-S2000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.13~10.18 | 2200 | D4HB | WAGON - LONG 5DR 7P | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 09.12~05.16 | 3300 | G6DF | PB813 LHD LONG 7P | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 01.13~10.18 | 3300 | G6DF | PB813 LHD PR | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 01.13~10.16 | 3300 | G6DH | WAGON - LONG 5DR 7P | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 08.15~01.19 | 2000 | D4HA | DM15 | RN1652V | PN0789 | RN1712 | PN0415 | FN0691 |
| 08.15~01.19 | 2000 | G4KH | DM | RN1652V | PN0537 | RN1712 | PN0415 | FN0691 |
| 08.15~01.19 | 2200 | D4HB | PDM15 RHD | RN1652V | PN0789 | RN1712 | PN0415 | FN0691 |
| 08.15~01.19 | 2400 | G4KE | PDM15 RHD | RN1652V | PN0789 | RN1712 | PN0415 | FN0691 |
| 07.16~02.18 | 2400 | G4KJ | DMA16 US | RN1652V | PN0592 | RN1712 | PN0415 | FN0691 |
| 11.15~11.18 | 3300 | G6DH | PB816 (USA) | RN1652V | PN0789 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2000 | D4HA | PDM12 KDOM | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2000 | G4KH | DMA US | RN1652V | PN0537 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2200 | D4HB | PDM12 | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2400 | G4KE | DM LHD | RN1652VRN1349V | PN0446 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 2400 | G4KE | DM RHD | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 05.12~07.15 | 3300 | G6DF | PDM12 | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 08.14~04.18 | 2000 | G4KH | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~11.20 | 2400 | G4KE | UM | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~04.18 | 2400 | G4KJ | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.17~11.20 | 2400 | G4KJ | PC618 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 11.14~10.20 | 3300 | G6DF | UM | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 08.14~04.18 | 3300 | G6DH | PC615 | RN1652V | PN0799 | RN1713 | PN0415 | FN0691 |
| 07.12~08.14 | 2000 | D4HA | XM12 | RN1349VRN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 2200 | D4HB | XM12 RHD | RN1349VRN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 07.12~08.14 | 3500 | G6DC | XM12 | RN1652V | PN0446 | RN1712 | PN0415 | FN0691 |
| 08.14~01.18 | 2000 | D4HA | PC | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2200 | D4HB | PC515 LHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~07.17 | 2200 | D4HB | PC515 LHD KDOM | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2200 | D4HB | PC515 RHD | RN1652VRN1349V | PN0662 | RN2008VRN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2400 | G4KE | PC515 LHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 2400 | G4KE | PC515 RHD | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
| 08.14~01.18 | 3300 | G6DF | UM | RN1652V | PN0662 | RN1713 | PN0457 | FN0754 |
