ROTOR DISC » RN2402

Specification

Type
Solid
Outter Ø
260
Num. of holes
4
Hole Ø:
12.8
Disc Thickness (Max)
9
Disc Thickness (Min)
8
Height
48.3
Centering Diameter
64.2
Pitch Circle Ø
114.3
Drum Ø:
157.3
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HONDA
42510-S0A-000
HONDA
42510-S84-A50
HONDA
42510-S84-A52
HONDA
42510-SY8-A00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.97~10.02 1800 F18B CF3 RN1093V PN8423 RN2402 PN8398
08.97~11.02 2000 F20B CF4 RN1621V PN8254 RN2402 PN8398
08.97~10.02 2000 F20B CF5 RN1621V PN8254 RN2402 PN8398
01.98~01.02 2000 F20B CL3 RN1621V PN8254 RN2402 PN8398
01.99~06.00 2000 F20B# CF9 RHD RN1248V PN8484 RN2402 FN5524PN8398
01.93~12.98 2000 F20B2 EURO RN1248V PN8484 RN2402 PN8398
01.98~01.03 2000 F20B5 CH3 PN8254 RN2402 PN8398
01.99~06.00 2000 F20B5 EURO PN8254 RN2402 PN8398
09.97~06.03 2300 F23A CG5 RHD RN1248V PN8484 RN2402 PN8398
12.99~12.02 2300 F23A1 CG6 RN1248V PN8484 RN2402 FN5524
02.02~12.02 2300 F23A5 EURO RN1248V PN8484 RN2402 PN8398FN5524
01.98~12.02 2000 F20B5 EURO PN8254 RN2402 PN8398
01.98~12.02 2300 F23A3 EURO RN1248V PN8484 RN2402 PN8398
09.97~10.02 2300 F23A CF6 RN1248V PN8484 RN2402 PN8398
09.97~10.02 2300 F23A CF7 RN1621V PN8254 RN2402 PN8398
08.97~10.02 1800 F18B CF3 RN1093V PN8423 RN2402 PN8398
08.97~10.02 2000 F20B CF4 RN1621V PN8254 RN2402 PN8398

Exemption from liability: the catalog data is advisory and can be used for reference only
