BRAKE SHOE » FN6600
Specification
Radius
90
Width
38
Thickness
4.8/7
Pcs In Set
2
Cross Reference
AKEBONO
NN-3027
BENDIX AUS
BS1563
HYUNDAI
59810-45060
HYUNDAI
59822-45002
HYUNDAI
59822-45060
HYUNDAI
59822-45A00
HYUNDAI
59822-45A20
HYUNDAI
59822-45A60
KASHIYAMA
K-6600-01
KASHIYAMA
K6600
MITSUBISHI
MC112501
MITSUBISHI
MC837950
MITSUBISHI
MT107334
MITSUBISHI
MT161474
MITSUBISHI
MZ981138
WVA
107334
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.10~ | 3900 | D4DC | HG17C | DN1882 | FN0679FN0832 | DN1882 | FN0679FN0832 | FN6600 |
| 01.04~01.10 | 3900 | D4DC11 | HD17CP | FN0635FN0679 | DN1483 | FN0679FN0635 | FN6600 |
| 01.09~ | 2600 | D4BB | CARGO HIGH | FN11003 | DN1482 | FN11003 | FN6600 | |
| 01.10~ | 3600 | D4AF | CARGO HIGH | FN0635 | DN1483 | FN0635 | FN6600 | |
| 09.04~04.10 | 3600 | D4AF | DUMP | FN0635 | FN11003FN0635 | FN6600 | ||
| 01.09~ | 3900 | D4DC | CARGO HIGH | DN1882 | FN0832 | DN1882 | FN0832 | FN6600 |
| 01.10~ | 3600 | D4AF | CARGO HIGH | DN1882 | FN0832 | DN1882 | FN0832 | FN6600 |
| 01.10~ | 3900 | D4DC | CARGO HIGH | DN1882 | FN0832 | DN1882 | FN0832 | FN6600 |
| 01.04~01.09 | 3900 | D4DC11 | CGK17 LHD | FN0635 | FN0635 | FN6600 | ||
| 01.98~01.05 | 3900 | D4DC11 | FGA17 RHD | FN0635 | DN1520 | FN0635 | FN6600 | |
| 01.04~01.09 | 3900 | D4DC11 | FGA17 RHD | FN0635PN0417 | FN0635 | FN6600 | ||
| 01.04~06.11 | 3900 | D4DC11 | FGA17 RHD | DN1512 | FN0679 | DN1512 | FN0679 | FN6600 |
| 01.98~01.15 | 3300 | D4AL | HD65 | FN11003 | DN1482 | FN11003 | FN6600 | |
| 01.04~ | 3600 | D4AF | HD65 | PN0417 | FN11003 | FN6600 | ||
| 01.04~01.10 | 3900 | D4DC11(4D34) | HD65 | FN0635 | FN0635 | FN6600 |
| 07.03~12.07 | 2000 | 4G63 | FA700 | PN3515 | FN6655PN3515 | FN6600 | ||
| 05.99~07.03 | 2000 | 4G63 | FB500B | RN1450V | PN3346 | FN4447 | FN6600 | |
| 05.99~06.02 | 2000 | 4G63 | FB510B | PN3347PN3346 | FN6655FN4447 | FN6600 | ||
| 09.85~09.89 | 2700 | 4DR5 | FB300B | PN3347FN6654PN3345 | FN6655FN6656 | FN6600 | ||
| 10.85~09.89 | 2700 | 4DR5 | FE300 | PN3347 | FN6602 | FN6600 | ||
| 10.85~09.89 | 2700 | 4DR5 | FE320 | PN3347 | FN6602 | FN6600 | ||
| 10.89~11.93 | 2800 | 4DR7 | FB308 | RN1260V | PN3347PN3345 | FN6655FN6656 | FN6600 | |
| 10.89~11.93 | 2800 | 4DR7 | FB328 | RN1260V | PN3347PN3345PN3346 | FN6655 | FN6600 | |
| 09.92~10.93 | 2800 | 4DR7 | FD378 | PN3346 | FN6655 | FN6600 | ||
| 10.93~04.99 | 2800 | 4M40 | FB501B | RN1450V | PN3346 | FN6655 | FN6600 | |
| 03.99~06.02 | 2800 | 4M40 | FB50A | PN3346 | FN4447FN6655 | FN6600 | ||
| 05.99~06.02 | 2800 | 4M40 | FB50AB | RN1450V | PN3346 | FN4447 | FN6600 | |
| 10.93~04.99 | 2800 | 4M40 | FB511A | RN1262V | PN3346 | FN6655 | FN6600 | |
| 10.93~01.06 | 2800 | 4M40 | FB511B | RN1260V | PN3347 | FN6655 | FN6600 | |
| 05.99~06.02 | 2800 | 4M40 | FB51AB | RN1774V | PN3346PN3347 | FN6655FN4447 | FN6600 | |
| 05.02~08.04 | 2800 | 4M40 | FB70A | RN1261V | PN3515 | FN6655PN3515 | FN6600 | |
| 05.02~01.07 | 2800 | 4M40 | FB70AB | RN1261V | PN3515 | FN6655 | FN6600 | |
| 10.93~05.99 | 2800 | 4M40 | FD501B | RN1450V | PN3346 | FN6655 | FN6600 | |
| 10.93~05.99 | 2800 | 4M40 | FD50A | PN3346 | FN6655 | FN6600 | ||
| 07.04~03.13 | 3000 | 4M42 | FB70BB | RN1261V | PN3515PN3812 | RN1550V | PN3812PN3515 | FN6600 |
| 10.85~11.93 | 3300 | 4D30 | FE301 | RN1260V | PN3347PN3175 | FN6602 | FN6600 | |
| 10.85~11.93 | 3300 | 4D30 | FE311 | PN3175FN6667 | FN6602 | FN6600 | ||
| 09.85~11.93 | 3300 | 4D30 | FE321 | PN3347PN3175 | FN6602 | FN6600 | ||
| 10.85~10.89 | 3300 | 4D30 | FE431 | PN3175 | FN6602 | FN6600 | ||
| 10.85~11.93 | 3300 | 4D30A | FE331 | PN3175 | FN6602 | FN6600 | ||
| 10.85~05.97 | 3600 | 4D32 | FE305 | PN3347PN3175 | FN6602 | FN6600 | ||
| 10.85~11.93 | 3600 | 4D32 | FE315 | FN6667PN3175PN3349 | FN6602 | FN6600 | ||
| 10.85~11.93 | 3600 | 4D32 | FE325 | FN6667PN3175PN3347 | FN6602 | FN6600 | ||
| 10.85~11.93 | 3600 | 4D32 | FE355 | FN6653 | FN6653BL1060 | FN6600 | ||
| 10.85~11.93 | 3600 | 4D32 | FE425 | DN1336 | FN6627FN6602 | FN6600 | ||
| 09.85~10.89 | 3600 | 4D32 | FE435 | FN6653 | FN6602BL1060 | FN6600 | ||
| 10.85~11.93 | 3600 | 4D32 | FE445 | FN6653 | BL1060FN6653 | FN6600 | ||
| 10.85~10.93 | 3600 | 4D32 | FE465 | FN6653 | BL1060FN6653 | FN6600 | ||
| 10.89~11.93 | 3600 | 4D32 | FG325 | FN6653 | FN6653BL1060 | FN6600 | ||
| 12.85~11.93 | 3600 | 4D32 | FG335 | FN6653 | FN6653BL1060 | FN6600 | ||
| 07.86~09.89 | 3600 | 4D32 | FG435E | FN6653 | FN6653BL1060 | FN6600 | ||
| 10.89~05.97 | 3600 | 4D32A | FE335EV | RN1262V | FN6653PN3349 | BL1060FN6602 | FN6600 | |
| 10.87~04.95 | 4200 | 4D33 | FE317 | PN3349 | FN6602 | FN6600FN6681 |
