DRUM BRAKE » DN1483

DN1483

Specification

Outter Ø
374
Num. of holes
5
Hole Ø
19.2
Centering Diameter
165
Height
134.1
Pitch Circle Ø
208
Drum Ø
320
Structure Material
G3000

Cross Reference

HYUNDAI
52761-5A101
HYUNDAI / KIA
52761-5A102
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   E-County

01.10~ 3900 D4DB CNB04EM FN0832 DN1483 FN0832 FN4443
01.04~01.10 3900 D4DC11 HD17CP FN0679FN0635 DN1483 FN0635FN0679 FN6600

HYUNDAI   »   HD45

01.10~ 3600 D4AF CARGO HIGH FN0635 DN1483 FN0635 FN6600

HYUNDAI   »   HD65

01.10~ 3900 D4DB CARGO HIGH FN0832 DN1483 FN0832 FN4443
