ROTOR DISC » RN22004V
Specification
Type
Vented
Outter Ø
237
Num. of holes
4
Disc Thickness (Max)
22
Height
43.7
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Disc Thickness (Min)
20
Drum Ø:
128
Structure Material
G3000
Cross Reference
NISSAN
40206-AX000
NISSAN
40206-CT40A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.02~11.08 | 1400 | CR14DE | BNZ11 | RN22004V | PN2452 | FN1264FN1198 | ||
| 10.02~11.08 | 1400 | CR14DE | BZ11 | RN22004V | PN2452 | DN1314 | FN1261 | |
| 05.05~11.08 | 1500 | HR15DE | YZ11 | RN22004V | PN2452 | DN1314 | FN1261 |
| 04.06~06.08 | 1500 | HR15DE | SC11 RHD | RN1995VRN22004V | PN2452 | DN1293 | FN1267 | |
| 04.06~06.08 | 1600 | HR16DE | SC11 | RN22004VRN1995V | PN2452 | DN1319DN1293 | FN1267 |
| 02.02~10.03 | 1000 | CR10DE | K12 JPN | RN22004V | PN2452 | DN1314 | FN1261 | |
| 02.02~07.10 | 1200 | CR12DE | AK12 | RN22003VRN22004V | PN2452 | DN1314 | FN1261 | |
| 02.02~06.07 | 1400 | CR14DE | BK12 | RN22004V | PN2452 | DN1314 | FN1261 | |
| 09.02~07.10 | 1400 | CR14DE | BNK12 | RN22004V | PN2452 | FN1198FN1264 | ||
| 02.02~08.10 | 1400 | CR14DE | K12 | RN1187VRN22004V | PN2452PN2800 | DN1314 | FN1255FN1261 | |
| 08.05~07.10 | 1500 | HR15DE | YK12 | RN22004V | PN2452 | DN1314 | FN1261 |
| 01.05~09.12 | 1500 | HR15DE | E11 | RN22004V | PN2452 | DN1314 | FN1261 | |
| 01.05~09.12 | 1500 | HR15DE | NE11 | RN22004V | PN2452 | FN1264 | ||
| 01.06~08.13 | 1600 | HR16DE | E11E | RN1187VRN22004V | PN2800 | DN1611DN1611H | FN1255 | |
| 10.08~09.12 | 1600 | HR16DE | ZE11 | RN22004V | PN2452 | DN1611DN1611H | FN1261 |
