ROTOR DISC » RN2248V

RN2248V

Specification

Type
Vented
Outter Ø
296
Num. of holes
6
Hole Ø:
16.5
Disc Thickness (Max)
38
Disc Thickness (Min)
35
Height
61
Centering Diameter
77
Pitch Circle Ø
130
Drum Ø:
166.3
Front/Rear
Front
Structure Material
G3000

Cross Reference

TOYOTA
43512-26200
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   GranAce

12.19~ 2800 1GD-FTV GDH303W RN2248V PN1861 RN2249V PN1862

TOYOTA   »   Hiace

02.19~ 2800 1GD-FTV GDH300R RN2248V PN1861 DN1116RN2249V FN0809PN1862
02.19~ 2800 1GD-FTV GDH301L RN2248V PN1861 DN1116RN2249V PN1862FN0809
12.19~ 2800 1GD-FTV GDH303 RN2248V PN1861 RN2249V PN1862FN0809
07.19~ 2800 1GD-FTV GDH306L RN2248V PN1861 RN2249V PN1862
07.19~ 2800 1GD-FTV GDH306R RN2248V PN1861 RN2249V PN1862
02.19~ 2800 1GD-FTV GDH320R RN2248V PN1861 DN1116RN2249V PN1862FN0809
03.19~ 2800 1GD-FTV GDH322L RN2248V PN1861 RN2249V PN1862
03.19~ 2800 1GD-FTV GDH322R RN2248V PN1861 RN2249V PN1862
02.19~ 3500 7GRFKS GRH320L RN2248V PN1861 RN2249VDN1116 PN1862FN0809
