DRUM BRAKE » DN1546
Specification
Outter Ø
290
Num. of holes
4
Hole Ø
13.7
Centering Diameter
65
Height
57.6
Pitch Circle Ø
100
Drum Ø
230
Structure Material
G3000
Cross Reference
SEAT
6K9 609 617
VAG
6K9 609 617
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.97~09.00 | 1400 | AKV | 9K9BA1 | RN1013RN1280V | PN0023W | DN1537DN1536DN1546 | FN0537FN0554 | |
| 12.97~06.03 | 1400 | APQ | 9K9___ | RN1013RN1280V | PN0023W | DN1537DN1546DN1536 | FN0537FN0554 | |
| 09.00~06.03 | 1400 | AUA | 9K9_E6 | RN1280V | PN0023W | DN1546 | FN0554 | |
| 09.00~06.03 | 1400 | AUD | 9K9_D_ | RN1280V | PN0023W | DN1546 | FN0554 | |
| 06.97~09.00 | 1600 | AEE | 9K9_5_ | RN1280V | PN0023W | DN1546DN1536DN1537 | FN0554FN0537 | |
| 07.96~09.00 | 1700 | AHB | 9K9_21 | RN1013RN1280V | PN0023W | DN1546DN1536DN1537 | FN0537FN0554 | |
| 11.95~06.03 | 1900 | 1Y | 9K9_Y1 | RN1013RN1280V | PN0018PN0023W | DN1536DN1537DN1546 | FN0554FN0537 | |
| 11.95~09.00 | 1900 | AEY | 9K9_Z1 | RN1280VRN1013 | PN0018PN0023W | DN1536DN1537DN1546 | FN0537FN0554 | |
| 10.96~09.00 | 1900 | AHU | 9K9_N_ | RN1280VRN1013 | PN0023W | DN1536DN1537DN1546 | FN0554FN0537 | |
| 09.97~09.00 | 1900 | ALE | 9K9BH1 | RN1280VRN1013 | PN0023W | DN1536DN1537DN1546 | FN0554FN0537 | |
| 09.00~06.03 | 1900 | ALH | 9K9_N_ | RN1280V | PN0018 | DN1546 | FN0554 | |
| 09.00~06.03 | 1900 | AYQ | 9K9_36 | RN1280V | PN0023W | DN1546 | FN0554 |
