ROTOR DISC » RN43004H
Specification
Type
Solid
Disc Thickness (Max)
9
Num. of holes
5
Height
86.2
Centering Diameter
52.3
Front/Rear
Rear
Outter Ø
260
Pitch Circle Ø
114.3
Structure Material
G3000
Disc Thickness (Min)
8
Cross Reference
RENAULT
43 20 000 10R
RENAULT
43 20 021 88R
RENAULT
43 20 065 06R
RENAULT
43 20 075 56R
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.12~03.19 | 1600 | M5M 400 | BHMM | RN1882V | PN0393 | RN43004H | PN0019W | |
| 09.12~08.16 | 1600 | M5M 401 | BHJ4 RS | RN1882V | PN0393 | RN43004H | PN0019W |
| 08.12~06.14 | 1200 | H5F 405 | KZ16 EST | RN43005VRN43007V | PN0551 | RN43004H | PN0019WPN0381 | |
| 03.08~04.16 | 1400 | H4J 700 | #Z | RN43005V | PN0551 | RN1572HRN43004H | PN0381PN0019W | |
| 03.14~04.16 | 1500 | K9K 636 | KZ14 WGN | RN43007V | PN0551 | RN43004H | PN0019W | |
| 01.10~07.16 | 2000 | M4R 713 | EZ1P | RN43007V | PN0551 | RN43004H | PN0381 |
| 04.12~09.16 | 1200 | H5F 400 | JZ# | RN43005V | PN0393 | RN43004HRN1881H | PN0381PN0019W | |
| 04.13~10.16 | 1500 | K9K 636 | JZ14 | RN43005V | PN0393 | RN43004HRN1881H | PN0730PN0019W | |
| 01.09~09.16 | 1500 | K9K 832 | JZ0 | RN43005V | PN0393 | RN43004H | PN0381PN0019W | |
| 04.09~09.16 | 1500 | K9K 837 | JZ09 | RN43005V | PN0393PN0551 | RN43004HRN1881H | PN0730PN0381PN0019W | |
| 01.09~09.16 | 1600 | K4M | JZ0V | PN0551 | RN43004H | PN0019WPN0381 | ||
| 01.09~09.16 | 2000 | M4R 711 | JZ0G | PN0551 | RN43004H | PN0381PN0019W |
