ROTOR DISC » RN1523V

RN1523V

Specification

Type
Vented
Disc Thickness (Max)
17
Num. of holes
4
Height
49
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
253
Drum Ø:
153
Disc Thickness (Min)
15
Structure Material
G3000

Cross Reference

OEM
4706749
OEM
4707288
OEM
93176389
OEM
93179462
SUZUKI
55311-84E01
SUZUKI
55311-84E01-000
SUZUKI
55311-86G02
SUZUKI
55311-86G02-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUBARU   »   Justy

01.03~12.07 1300 M13A G3X RN1523V PN9807 FN0032
01.03~12.07 1500 M15A G3X RN1523V PN9807 FN0032

SUZUKI   »   Ignis

01.03~01.08 1300 M13A HX51 RN1523V PN9807 DN1373DN1412 FN9977
06.03~01.08 1300 Z13DT HX91S 5DR HB LHD RN1523V PN9807 DN1373 FN9977
01.03~01.08 1500 M15A MHX81 RN1523V PN9807 DN1373DN1412 FN9977

SUZUKI   »   Solio

08.05~12.10 1300 M13A MA34S RN1131RN1523V PN9807PN9406 FN9959
