ROTOR DISC » RN1131

RN1131

Specification

Type
Solid
Disc Thickness (Max)
12
Num. of holes
4
Height
44
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
246.5
Disc Thickness (Min)
10
Drum Ø:
125
Structure Material
G3000

Cross Reference

BENDIX
562124B
OPEL
4700711
SUZUKI
55311-83E00
VAUXHALL
9193872
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

OPEL   »   Agila (A)

09.00~03.08 1000 Z10XE RN1131 PN9805PN9807 DN1569DN1567DN1568 FN0762FN2386
09.00~08.04 1200 Z12XE RN1131 PN9805PN9807 DN1569DN1567DN1568 FN0762FN2386

SUZUKI   »   Solio

08.05~12.10 1300 M13A MA34S RN1131RN1523V PN9807PN9406 FN9959

SUZUKI   »   Wagon R

07.01~01.07 1000 G10A RB310 RN1131 PN9807 DN1567DN1569 FN9959FN9977

SUZUKI   »   Wagon R+

02.00~01.05 1300 G13BB MMMA53S LHD RN1131 PN9807 DN1569DN1567 FN9977FN9959
