ROTOR DISC » RN1462V

Specification

Type
Vented
Disc Thickness (Max)
17
Num. of holes
4
Height
42
Centering Diameter
55
Front/Rear
Front
Outter Ø
246
Pitch Circle Ø
100
Drum Ø:
137
Disc Thickness (Min)
16
Structure Material
G3000

Cross Reference

DAIHATSU
43512-97402-000
DAIHATSU
43512-B1110
TOYOTA
43512-97402
TOYOTA
43512-B1020
TOYOTA
43512-B1021
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.06~02.10 900 KJ-VE M312S RN1481VRN1462V PN9443 FN0030
04.16~ 1000 1KR-FE M700S RN1462V PN9443 DN1433 FN0046
04.16~ 1000 1KR-FE M710S RN1462V PN9443 FN2397
05.02~09.12 660 JB-DET L880K RN1462V PN6492 FN0037
06.14~ 660 KF LA400K RN1462V PN9443 FN2397
05.02~09.12 1300 K3-VE AL881K RN1462V PN9443 FN0037
01.05~10.11 1000 1KR-FE M300 RN1462V PN6492PN5544 FN2397
10.04~10.11 1300 K3-VE M301S RN1462VRN1481V PN6492 DN1433 FN2397
01.05~10.11 1300 K3-VE M311 RN1462V PN9443 FN2397
08.00~08.05 1300 K3-V# M201G JPN RN1462VRN1481V PN6427PN9443 FN0037
08.00~08.05 1300 K3-VE M201G RN1481VRN1462V PN9443PN6427 FN0037
05.05~06.11 1300 K3-VE M301 RN1954VRN1462VRN1481V PN5562PN9443 FN0029FN0037
06.11~11.17 1300 K3-VE M600 RN1481VRN1954VRN1462V PN9443PN5562 FN0037FN0029
01.06~07.16 1300 K3-VE QNC20 RN1462V PN9443 DN1433 FN2397
01.06~09.14 1300 K3-VE QNC25 RN1462V PN9443 FN0041
01.06~07.16 1500 3SZ-VE QNC21 RN1462V PN9443 DN1433 FN2397
04.16~ 1000 1KR-FE M700A RN1462V PN9443 DN1433 FN0046
04.16~ 1000 1KR-FE M710A RN1462V PN9443 FN2397

Exemption from liability: the catalog data is advisory and can be used for reference only
