ROTOR DISC » RN1325
Specification
Type
Solid
Disc Thickness (Max)
12
Num. of holes
4
Height
58.5
Centering Diameter
60
Front/Rear
Rear
Pitch Circle Ø
115
Outter Ø
276
Drum Ø:
163
Disc Thickness (Min)
10
Structure Material
G3000
Cross Reference
CHEVROLET
96328254
OEM
XFL9050445
SUZUKI
55611-86Z00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.06~01.12 | 2000 | X20D1 | LA69 GR | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 06.06~01.12 | 2000 | X20D1/LBM | LF69 LHD EU | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 10.08~01.13 | 2000 | X20D1/LBM | LF69 LHD RUS | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 06.06~01.12 | 2000 | X20D1/LBM | VJ5 GL | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 01.07~01.12 | 2000 | Z20S / LLW | LA69 | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 06.04~01.06 | 2500 | LBK | 1VD69 CANADA | RN1323V | PN0380 | RN1325 | PN52082PN0375 | FN0658 |
| 06.06~01.12 | 2500 | X25D1 | LA69 | RN1323V | PN0380 | RN1325 | PN52082 | FN0658 |
| 07.02~06.06 | 2000 | X20SED | LA69 | RN1324V | PN0374 | RN1325 | PN0375 | FN0658 |
| 07.02~06.06 | 2000 | X20SED | LF69 | RN1324V | PN0374 | RN1325 | PN0375 |
