NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1323V

ROTOR DISC » RN1323V

Specification

Type

Vented

Disc Thickness (Max)

24

Num. of holes

4

Height

47.5

Centering Diameter

60

Front/Rear

Front

Pitch Circle Ø

114.3

Outter Ø

278

Drum Ø:

142

Disc Thickness (Min)

22

Structure Material

G3000

Cross Reference

CHEVROLET

96329364

CHEVROLET (GM)

95962084

GM

96329364

SUZUKI

55311-86Z00

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CHEVROLET (GM) » Epica

06.06~01.12	2000	X20D1	LA69 GR	RN1323V	PN0380	RN1325	PN0375	FN0658
06.06~01.12	2000	X20D1	VJ5 GL	RN1323V	PN0380	RN1325	PN0375	FN0658
06.06~01.12	2000	X20D1/LBM	LF69 LHD EU	RN1323V	PN0380	RN1325	PN0375	FN0658
01.07~01.12	2000	Z20S / LLW	LA69	RN1323V	PN0380	RN1325	PN0375	FN0658
06.04~01.06	2500	LBK	1VD69 CANADA	RN1323V	PN0380	RN1325	PN0375	FN0658
06.06~01.12	2500	X25D1	LA69	RN1323V	PN0380	RN1325	PN0375	FN0658

DAEWOO » Epica

02.07~

2000

Z20S / LLW

KL1

RN1323V

PN0380

PN0375
