ROTOR DISC » RN1202V

Specification

Type
Vented
Disc Thickness (Max)
25
Num. of holes
4
Height
43.3
Centering Diameter
60
Pitch Circle Ø
98
Front/Rear
Front
Outter Ø
280
Hole Ø:
14.4
Disc Thickness (Min)
22
Drum Ø:
139
Structure Material
G3000

Cross Reference

BENDIX
562278B
BENDIX EUR
562315B
GM
569006
GM
93181113
GM
93197712
OPEL
05 69 006
OPEL
05 69 007
OPEL
05 69 067
OPEL
569006
OPEL
569007
OPEL
569067
VAUXHALL
93175376
VAUXHALL
93181113
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.04~03.10 1800 Z18XE RN1112VRN1202V PN0355 RN1380RN1801 PN0329
03.04~10.10 1400 Z14XE# F48 RN1202VRN1110V PN0355PN0118 RN1380 PN0329
03.04~10.10 1400 Z14XE# L48 RN1110VRN1202V PN0118PN0355 RN1380 PN0329
03.04~12.14 1400 Z14XEP A04 RN1202V PN0355 RN1800DN1593 FN0599PN0329FN0782
03.04~12.14 1600 Z16XEP A04 RN1202V PN0355 DN1593RN1800 PN0329FN0782FN0599
03.04~12.13 1800 Z18XE E35 RN1202VRN1112V PN0325 RN1801RN1380 PN0329FN0599
03.04~03.14 1800 Z18XER L48 RN1202VRN1112V PN0355PN0325 RN1380RN1801 PN0329
01.08~01.15 2000 Z20LEH L08 RN2056VRN1202V PN0325 RN1801 FN0599PN0329
09.04~03.14 2000 Z20LER L48 RN1392VRN1202V PN0355PN0325 RN1801RN1380 PN0329
06.04~01.12 1300 Z13DTJ F25 RN1647VRN1202V PN0355 DN1593RN1648 FN0599PN0329
06.04~01.12 1400 Z14XE RN1112VRN1202V PN0355 PN0329
09.03~11.06 1300 Z13DT F25 RN1647VRN1202V PN0361PN0355 RN1648 PN0329
09.03~05.10 1700 Y17DT X03 RN1202V PN0355 PN0329
09.03~05.10 1700 Z17DT# X03 RN1202V PN0355 PN0329

Exemption from liability: the catalog data is advisory and can be used for reference only
