ROTOR DISC » RN1054
Specification
Type
Solid
Disc Thickness (Max)
10
Num. of holes
4
Height
49
Centering Diameter
64
Front/Rear
Rear
Outter Ø
260
Disc Thickness (Min)
8
Pitch Circle Ø
114.3
Drum Ø:
155
Structure Material
G3000
Cross Reference
BENDIX
561952B
HONDA
42510-SM4-950
HONDA
42510-SV4-J00
HONDA
42510SMA950
HONDA
42510SN7000
HONDA
42510SV4A00
OEM
24510SM4950
OEM
42510SV1A00
OEM
42510SV4A00
ROVER
GBD90835
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.98~12.02 | 1600 | A16A5 | CF | RN1093V | PN8423 | RN1054 | FN28001 | |
| 09.89~09.93 | 1800 | F18A | CB1 | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 09.89~09.93 | 1800 | F18A | CB2 | PN8223 | RN1054 | PN8398FN5520 | ||
| 02.96~01.98 | 1800 | F18A# | CE7 EU | RN1030V | PN8293PN8254 | RN1054 | PN8398 | |
| 01.94~12.96 | 1800 | F18A/3/4 | EURO | RN1030V | PN8293PN8254 | RN1054 | PN8398 | |
| 10.93~09.97 | 1800 | F18B | CD3 | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 01.96~12.97 | 1800 | F18B | EURO | RN1030V | PN8223 | RN1054 | FN5520PN8398 | |
| 01.99~12.00 | 2000 | 20T2N | EURO | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.96~12.98 | 2000 | 20T2N# | CF1 EU | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.96~12.96 | 2000 | 20T2N14/15 | EURO | RN1030V | PN8293 | RN1054 | PN8398 | |
| 09.89~09.93 | 2000 | F20A | CB3 | RN1030V | PN8223 | RN1054 | PN8398 | |
| 04.90~02.94 | 2000 | F20A1/3/8 | EURO | RN1030V | PN8484 | RN1054 | PN8398FN5524 | |
| 09.93~09.97 | 2000 | F20B | CD4 JPN | RN1030V | PN8223 | RN1054 | PN8398FN5520 | |
| 09.93~09.97 | 2000 | F20B | CD4 RHD | RN1030V | PN8484PN8223 | RN1054 | PN8398FN5520 | |
| 01.93~12.98 | 2000 | F20B1 | EURO | RN1030V | PN8484 | RN1054 | PN8398FN5524 | |
| 01.93~09.98 | 2000 | F20Z1 | CE8 | PN8293 | RN1054 | PN8397 | ||
| 02.93~09.98 | 2000 | F20Z1/2 | CC7 EU | RN1030V | PN8293 | RN1054 | PN8398 | |
| 01.93~12.96 | 2000 | F20Z1/2 | EURO | RN1030V | PN8254PN8293 | RN1054 | PN8398 | |
| 01.92~02.94 | 2200 | F22A | CB7 | RN1030V | PN8814PN8223 | RN1054 | PN8398 | |
| 04.91~02.94 | 2200 | F22A | CB9 | PN8223PN8254 | RN1054 | PN8398 | ||
| 01.90~12.93 | 2200 | F22A | EURO | RN1030V | PN8484PN8814 | RN1054 | FN5524PN8398 | |
| 10.94~12.98 | 2200 | F22B1 | CD5 RHD | RN1030V | PN8484 | RN1054 | PN8398 | |
| 01.94~12.97 | 2200 | F22B1-5 | EURO | RN1030V | PN8223 | RN1054 | PN8398FN5524 | |
| 06.96~06.99 | 2200 | F22Z2 | CE9 | PN8254 | RN1054 | PN8398 | ||
| 01.96~12.97 | 2200 | F22Z4 | EURO | RN1030V | PN8254PN8484 | RN1054 | PN8398 | |
| 09.93~09.97 | 2200 | H22A | CD6 | PN8254 | RN1054 | PN8398 | ||
| 09.97~01.02 | 2200 | H22A1 | EURO | PN8254 | RN1054 | PN8398 | ||
| 01.93~12.95 | 2300 | H23A3 | CC7 EU | PN8254 | RN1054 | PN8398 | ||
| 01.93~12.94 | 2300 | H23A3 | EURO | PN8254 | RN1054 | PN8398 | ||
| 01.95~12.97 | 2700 | C27A4 | EURO | PN8254 | RN1054 | PN8398 |
| 09.93~12.98 | 2000 | F20B | EURO | PN8254 | RN1054 | PN8397 | ||
| 01.95~12.98 | 2000 | F20B3 | CD9 EU | PN8254 | RN1054 | PN8397 | ||
| 08.93~12.98 | 2200 | F22B | CD7 | PN8254PN8484 | RN1054 | PN8398 | ||
| 08.93~12.98 | 2200 | F22B | CD9 US | RN1030V | PN8254PN8484 | RN1054 | PN8398 | |
| 08.93~12.98 | 2200 | F22B2 | EURO | RN1030V | PN8484PN8254 | RN1054 | PN8398 | |
| 03.94~09.97 | 2200 | H22A | CD8 | PN8254 | RN1054 | PN8398 |
| 01.94~02.98 | 2000 | F20B3 | CE2 EU | PN8254 | RN1054 | PN8398PN8397 | ||
| 09.93~12.97 | 2000 | F20Z | EURO | PN8254 | RN1054 | PN8398 | ||
| 01.91~12.97 | 2200 | F22A | EURO | PN8254 | RN1054 | PN8398 | ||
| 02.94~09.97 | 2200 | F22B | CE1 | RN1030V | PN8484 | RN1054 | PN8398 | |
| 09.93~12.98 | 2200 | F22B | CE1 US | PN8254 | RN1054 | PN8398 | ||
| 08.96~01.98 | 2200 | H22A | CF2 | PN8254 | RN1054 | PN8398 |
