ROTOR DISC » RN2103V

RN2103V

Specification

Type
Vented
Outter Ø
330
Num. of holes
6
Disc Thickness (Max)
30
Disc Thickness (Min)
28.5
Height
95.5
Centering Diameter
78.8
Pitch Circle Ø
139.7
Drum Ø:
210
Front/Rear
Rear

Cross Reference

GM
15065077
GM
15712802
GM
15727134
GM
25757802
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CADILLAC (GM)   »   Escalade ESV

02.01~01.06 6000 LQ9 TK15906 PN0055 RN2103V PN0056 FN0705
01.02~12.06 6000 LQ9 TK15936 PN0055 RN2103V PN0056 FN0705

CHEVROLET (GM)   »   Avalanche

09.01~04.06 5300 LM7 GMT800 PN0055PN0409 RN2103V PN0056PN0076PN0656 FN0705

CHEVROLET (GM)   »   Express G1500 Van

01.08~12.14 5300 LMF HHR PANEL TRUCK PN0055 RN2103V PN0656 FN0705

CHEVROLET (GM)   »   Suburban

12.99~01.06 5300 LM7 CK15906 PN0055 RN2103V PN0056 FN0705
09.99~08.06 6000 LQ4 TK10906 PN0055 RN2103V PN0056 FN0705

CHEVROLET (GM)   »   Tahoe

01.04~06.07 5300 L59 CK15706 PN0055 RN2103V PN0056 FN0705
