ROTOR DISC » RN2014

Specification

Type
Solid
Outter Ø
289.8
Num. of holes
5
Disc Thickness (Max)
10
Height
46
Centering Diameter
107
Pitch Circle Ø
139.7
Drum Ø:
177
Front/Rear
Front
Structure Material
G3000

Cross Reference

BENDIX
561424B
SUZUKI
5521180000
SUZUKI
5551180000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.87~03.90 550 F5A-T JA71 RN2014 PN9118 FN9921
02.90~10.95 660 F6A-T JA11V RN2014 PN9118 FN9921
01.88~01.05 1300 G13A SJ413 RN2014 PN9008 DN1361 FN9921

Exemption from liability: the catalog data is advisory and can be used for reference only
