ROTOR DISC » RN2642

Image Not Available

Specification

Type
Solid
Outter Ø
330
Num. of holes
5
Hole Ø:
12.6
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
41.1
Centering Diameter
62
Pitch Circle Ø
108
Drum Ø:
148
Front/Rear
Rear
Structure Material
G3000

Cross Reference

JETOUR
F16-3502075YT
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

JETOUR   »   Dashing

09.22~ 1500 SQRE4T15C X-1 RN2640VRN2580V PN81001 RN2642RN2641
09.22~ 1600 SQRF4J16 X-1 RN2580VRN2640V PN81001 RN2642RN2641
