ROTOR DISC » RN2640V

Specification

Type
Vented
Outter Ø
325.4
Num. of holes
5
Hole Ø:
13.2
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
45.3
Centering Diameter
62
Pitch Circle Ø
108
Drum Ø:
141.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

JETOUR
F01-3001075
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.22~ 1500 SQRE4T15C X-1 RN2640VRN2580V PN81001 RN2641RN2642
09.22~ 1600 SQRF4J16 X-1 RN2640VRN2580V PN81001 RN2642RN2641
10.20~ 1600 SQRF4J16 X70PLUS RN2640V PN8052PN81001 RN2641 PN8051
09.21~ 1600 SQRF4J16 X90PLUS RN2640V RN2641
11.22~ 2000 SQRF4J20 X90PLUS RN2640V RN2641

Exemption from liability: the catalog data is advisory and can be used for reference only
