ROTOR DISC » RN2619V

Image Not Available

Specification

Type
Vented
Outter Ø
325
Num. of holes
5
Hole Ø:
13
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
50
Centering Diameter
64
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GREAT WALL
3502011XKZ1DA
HAVAL
3502011XKZ1DA
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HAVAL   »   H6

04.17~ 2000 GW4C20 H6 RN1415VRN2556V PN6046PN6048 RN2619V PN8813
Copyright © 2003-2024 JNBK Corporation. All Rights Reserved

Exemption from liability: the catalog data is advisory and can be used for reference only
