ROTOR DISC » RN2614

Specification

Type

Solid

Outter Ø

253

Num. of holes

9

Disc Thickness (Max)

10

Height

50

Centering Diameter

65

Front/Rear

Rear

Structure Material

G3000

Hole Ø:

15.4

Disc Thickness (Min)

8

Pitch Circle Ø

112

Drum Ø:

140

Cross Reference

MG

10722873

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MG (SAIC) » MG 5

05.23~	1500	15FCD		RN2613V	PN0148W PN0348W	RN2614 RN2634	PN33003 PN6069
11.20~	1500	15S4C		RN2613V	PN0148W	RN2614	PN6069
