NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2613V

Product
Application

ROTOR DISC » RN2613V

Specification

Type

Vented

Outter Ø

280

Num. of holes

9

Disc Thickness (Max)

22

Disc Thickness (Min)

20

Height

43.2

Centering Diameter

65

Front/Rear

Front

Structure Material

G3000

Hole Ø:

15.4

Pitch Circle Ø

112

Drum Ø:

144

Cross Reference

MG

10722871

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MG (SAIC) » MG 5

05.23~	1500	15FCD		RN2613V	PN0348W PN0148W	RN2634 RN2614	PN33003 PN6069
11.20~	1500	15S4C		RN2613V	PN0148W	RN2614	PN6069
