ROTOR DISC » RN2540

Specification

Type
Solid
Outter Ø
311
Num. of holes
5
Hole Ø:
13.1
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
34
Centering Diameter
62
Pitch Circle Ø
108
Drum Ø:
142.2
Front/Rear
Rear
Structure Material
G3000

Cross Reference

Chery
204000479AA
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.21~ 1500 SQRE4T15C T1E RN2326V PN0377 RN2540 PN6041
03.20~ 1500 SQRE4T15C T1E RN2326V PN0377 RN2540 PN6041
03.23~ 1500 SQRE4T15C T1EFL1 PN8802 RN2540 PN6041
09.21~ 1500 SQRE4T15C T1EFL1 RN2326V PN0377 RN2540 PN6041
08.23~ 1600 SQRF4J16B T1EFL1 RN2326V PN0377 RN2540 PN6041
07.20~ 1500 SQRE4T15C T1C RN2326V PN0377 RN2540 PN6041

Exemption from liability: the catalog data is advisory and can be used for reference only
