NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1936V

Product
Application

ROTOR DISC » RN1936V

Specification

Type

Vented

Outter Ø

320

Num. of holes

5

Disc Thickness (Max)

28

Disc Thickness (Min)

26

Height

47.1

Centering Diameter

64

Pitch Circle Ø

114.3

Drum Ø:

153.3

Structure Material

G3000

Front/Rear

Front

Hole Ø:

12.7

Cross Reference

HONDA

45251-TZ3-A00

HONDA

45251-TZ5-A00

HONDA

45251-TZ5-A01

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

ACURA » MDX

06.13~12.20	3500	J35Y4	YD3	RN1936V RN2219V	PN0645	RN1937	PN0648 PN0646	FN8005
05.13~06.16	3500	J35Y4	YD4	RN1936V RN2632V	PN0645	RN1937	PN0648 PN0646	FN8005

ACURA » TLX

07.14~07.20	2400	K24W7	UB1	RN1936V RN1406V	PN28003 PN8865	RN1695	PN0648
07.14~07.20	3500	J35Y6	UB2,UB3	RN1406V RN1936V	PN28003 PN8865	RN1695	PN0648
