BRAKE SHOE » FN0810

Specification

Radius
93
Width
22
Thickness
3.2
Pcs In Set
4

Cross Reference

Chery
T15-6GN3502170
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.19~ 1500 SQRE4G15B / SQRE4G15C T19 RN2573V PN0838 RN2558RN2574 PN0846 FN0810
08.19~ 2000 SQRD4G20 T19 RN2501V PN8002 RN2502RN2558 PN8005PN0846 FN0810
04.16~11.20 1500 SQRE4T15 T15 RN2501V PN8002 RN2502RN2558 PN0846PN8005 FN0810
06.13~11.20 2000 SQRD4G20 T15 RN2501V PN8002 RN2558RN2502 PN8005PN0846 FN0810

Exemption from liability: the catalog data is advisory and can be used for reference only
