ROTOR DISC » RN1913

RN1913

Specification

Type
Solid
Outter Ø
285
Num. of holes
5
Disc Thickness (Max)
10
Height
51
Centering Diameter
67
Front/Rear
Rear
Disc Thickness (Min)
9
Pitch Circle Ø
124
Drum Ø:
144
Structure Material
G3000

Cross Reference

SSANGYONG
48401-35000
SSANGYONG
4840135001
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SSANGYONG   »   Tivoli

03.20~ 1200 G12DTF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
06.19~ 1500 G15DTF X100 RHD RN1912V PN0587 RN1913 PN0538PN0591 FN0664
01.15~06.19 1600 D16DTF X100 LHD RN1912V PN0587 RN1913RN1957 PN0591PN0538 FN0664
01.15~06.19 1600 D16DTF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
06.19~ 1600 D16DTF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
01.15~06.19 1600 G16DF X100 LHD RN1912V PN0587 RN1913 PN0538PN0591 FN0664
01.15~06.19 1600 G16DF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
01.15~ 1600 XDi 160 X100 RN1912V PN0587 RN1913 PN0538 FN0664

SSANGYONG   »   XLV

01.15~06.19 1600 G16DF X100 RHD RN1912V PN0587 RN1913 PN0591
