ROTOR DISC » RN1912V

RN1912V

Specification

Type
Vented
Outter Ø
298
Num. of holes
5
Disc Thickness (Max)
23
Height
37.5
Centering Diameter
67
Front/Rear
Front
Disc Thickness (Min)
21.4
Pitch Circle Ø
112
Drum Ø:
146
Structure Material
G3000

Cross Reference

SSANGYONG
41441-35000
SSANGYONG
41441-35001
SSANGYONG
4144135002
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SSANGYONG   »   Tivoli

03.20~ 1200 G12DTF X100 RHD RN1912V PN0587 RN1913 PN0538PN0591 FN0664
06.19~ 1500 G15DTF X100 RHD RN1912V PN0587 RN1913 PN0538PN0591 FN0664
01.15~06.19 1600 D16DTF X100 LHD RN1912V PN0587 RN1957RN1913 PN0591PN0538 FN0664
01.15~06.19 1600 D16DTF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
06.19~ 1600 D16DTF X100 RHD RN1912V PN0587 RN1913 PN0538PN0591 FN0664
01.15~06.19 1600 G16DF X100 LHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
01.15~06.19 1600 G16DF X100 RHD RN1912V PN0587 RN1913 PN0591PN0538 FN0664
01.15~ 1600 XDi 160 X100 RN1912V PN0587 RN1913 PN0538 FN0664

SSANGYONG   »   XLV

01.15~06.19 1600 G16DF X100 RHD RN1912V PN0587 RN1913 PN0591
