ROTOR DISC » RN1832V

RN1832V

Specification

Type
Vented
Outter Ø
368
Num. of holes
5
Disc Thickness (Max)
36
Height
68.7
Centering Diameter
85
Pitch Circle Ø
130
Disc Thickness (Min)
34
Drum Ø:
157
Structure Material
G3000
Front/Rear
Front

Cross Reference

VAG
7L8 615 301 A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

VOLKSWAGEN   »   Touareg

08.07~05.10 5000 CBWA 7L64A3 RN1832V PN0529 RN1738V PN0530 FN0638
