BRAKE SHOE » FN9932

Specification

Radius
90
Width
35
Thickness
3.2
Pcs In Set
4

Cross Reference

AKEBONO
NN5524
KASHIYAMA
K9932
MAZDA
1A00-33-330
MAZDA
ZZS0-33-330
MAZDA
ZZS1-33-330
SUZUKI
52200-80810
SUZUKI
52210-85030
SUZUKI
52210-85040
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.89~02.90 550 F5B DG41B FN9932PN9408 FN9919
05.89~02.90 550 F5B DG41T PN9408FN9932 FN9919
05.89~02.90 550 F5B DG41V FN9932PN9408 FN9919
02.90~08.91 660 F6A DG51B FN9932 FN9919
02.90~08.91 660 F6A DG51T FN9932PN9408 FN9919
02.90~08.91 660 F6A# DG51V FN9932PN9408 FN9923FN9919
03.85~05.89 550 F5A DA71T FN9932FN9918PN9124 FN9919
03.85~05.89 550 F5A# DA71V FN9932FN9918PN9124 FN9919
05.89~03.90 550 F5B DA41T PN9408FN9932 FN9919
05.89~03.90 550 F5B# DA41V PN9408FN9932 FN9919
03.90~09.91 660 F6A DA51T FN9932PN9408 FN9919
09.91~04.99 660 F6A DC51B PN9408FN9932 FN9943
03.90~12.92 660 F6A DD51# RN2129 FN9932PN9408 FN9952FN9932FN9919FN9943FN9951
09.91~04.99 660 F6A# DC51T PN9408FN9932 FN9919FN9943FN9951

Exemption from liability: the catalog data is advisory and can be used for reference only
