ROTOR DISC » RN2129
Specification
Type
Solid
Outter Ø
215
Num. of holes
4
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
33
Centering Diameter
86
Pitch Circle Ø
102
Drum Ø:
106
Front/Rear
Front
Structure Material
G3000
Cross Reference
BENDIX
561425B
DAEWOO
91122289
DAEWOO
96052404
GM
91122289
GM
96052404
MARUTI
55511M82000
MARUTI
55511M82010
OEM
30005701
OEM
55311A60B11000
OEM
55511-82010
OEM
5551160B11
OEM
5551182
OEM
55511M82001
SUZUKI
55311-60B11
SUZUKI
5531160B11A00
SUZUKI
55311A60B11
SUZUKI
55511-78400
SUZUKI
55511-78401
SUZUKI
55511-82000
SUZUKI
55511-82001
SUZUKI
55511-M82000
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.85~05.89 | 550 | F5A | DB71T | RN2129 | FN9910PN9124 | FN9919 | ||
| 03.85~05.89 | 550 | F5A | DB71V | RN2129 | PN9124FN9910 | FN9919 | ||
| 05.89~03.90 | 550 | F5B | DB41T | RN2129 | PN9408 | FN9919 | ||
| 03.90~09.91 | 660 | F6A | DB51T | RN2129 | PN9408 | FN9919 | ||
| 03.90~05.95 | 660 | F6A | DD51# | RN2129 | FN9932PN9408 | FN9951FN9952FN9932FN9919FN9943 | ||
| 01.90~09.91 | 660 | F6A# | DA51V | RN2129 | PN9408 | FN9923FN9919 | ||
| 03.90~09.91 | 660 | F6A# | DB51V | RN2129 | PN9408 | FN9923 | ||
| 09.91~12.98 | 660 | F6A# | DF51V | RN2129 | PN9408 | FN9943 |
