ROTOR DISC » RN2426

RN2426

Specification

Type
Solid
Outter Ø
305
Num. of holes
5
Hole Ø:
12.5
Disc Thickness (Max)
11
Disc Thickness (Min)
9
Height
35
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
58411-P2000
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Santa FE

06.20~ 2200 D4HE PS120 DOM RN2305V PN6135 RN2426 PN6130
06.20~ 2200 D4HH PS120 RN2305V PN6135 RN2426 PN6130
06.20~ 2500 G4KM PS120 LHD RN2305V PN6135 RN2426 PN6130

KIA   »   Sorento

02.20~ 2200 D4HE PGZ20 RHD RN2305VRN2317V PN6135 RN2308VRN2426 PN6130
