ROTOR DISC » RN2308V
Specification
Type
Vented
Outter Ø
325
Num. of holes
5
Hole Ø:
12.5
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
35
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Rear
Structure Material
G3000
Cross Reference
HYUNDAI / KIA
58411-P2700
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.20~ | 2500 | G4KM | KEURPS120 | RN2305VRN2317V | PN6135 | RN2308V | PN6130 | |
| 11.23~ | 2500 | G4KN | PHH24 | RN2305V | PN6135 | RN2308VRN2426 | PN6130 | |
| 11.23~ | 2500 | G4KP | PHH24 | RN2305V | PN6135 | RN2308VRN2426 | PN6130 |
| 01.20~ | 1600 | G4FT | PHC20 RHD | RN2305V | PN6135 | RN2308V | PN6130 | |
| 07.19~ | 2200 | D4HE | PGZ20 LHD | RN2317VRN2305V | PN6135 | RN2308V | PN6130 | |
| 02.20~ | 2200 | D4HE | PGZ20 RHD | RN2317VRN2305V | PN6135 | RN2426RN2308V | PN6130 | |
| 04.19~ | 2500 | G4KM | PGZ20 | RN2305VRN2317V | PN6135 | RN2308V | PN6130 | |
| 01.20~ | 3500 | G6DU | PGZ20 | RN2317VRN2305V | PN6135 | RN2308V | PN6130 |
