ROTOR DISC » RN1711V

RN1711V

Specification

Type
Vented
Front/Rear
Front
Num. of holes
5
Pitch Circle Ø
114.3
Outter Ø
345
Disc Thickness (Max)
30
Height
56
Centering Diameter
69
Drum Ø:
145
Disc Thickness (Min)
28.4
Structure Material
G3000

Cross Reference

HYUNDAI
51712-3N500
HYUNDAI
51712-3N600
HYUNDAI / KIA
51712-2M900
HYUNDAI / KIA
51712-3N000
HYUNDAI / KIA
51712-3N900
HYUNDAI / KIA
51712-B1700
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

GENESIS   »   G80

03.16~12.20 2200 D4HC PB116 RN2610VRN1711V PN0633 RN2148 PN0415PN0649 FN0758

HYUNDAI   »   Centennial / Equus

01.13~01.15 3800 G6DJ BHL13 RN1711V PN0633 RN1654V PN0415 FN0783
09.09~05.13 3800 G6DK BHL08 RN1711V PN11002PN0633 RN1654V PN0415 FN0666

HYUNDAI   »   Genesis

01.14~11.16 3000 G6DG GN41 RN1711V PN0633PN0537 RN2148 PN0649 FN0758
01.14~11.16 3800 G6DJ GN41 RN1711V PN0633 RN2148 PN0649 FN0758
01.14~11.16 3800 G6DJ PB114 US RN1711V PN0633 RN2148 PN0649 FN0758
01.08~01.14 5000 G8BE GC4D RN1711V PN11002 RN2148 PN0649 FN0666

HYUNDAI   »   Genesis Coupe

11.08~03.12 2000 G4KF DK08 RN1711V PN0150SPN0633 RN1654V PN0415 FN0666

KIA   »   K9

09.11~03.18 3800 G6DK DH11 RN1711V PN0633 RN2148 PN0649

KIA   »   K900

09.11~03.18 3800 G6DK DH11 RN1711V PN0633 RN2148 PN0649

KIA   »   Quoris

09.11~ 3800 G6DJ DH11 RN1711V PN0633 RN2148 PN0649 FN0783FN0666
09.11~ 3800 G6DK DH11 RN1711V PN0633 RN2148 PN0649 FN0666FN0783
